Princess 9 2MR

	Engine	Honda GX160 OHV Start recoil starter Supply fuel Displacement 163 cc, 1 Cylinder Power 4.8 HP (3.6 kW) Air cooled Oil bath air filter
	Engine	Grillo EX17 OHC Start recoil starter Supply fuel Displacement 169 cc, 1 Cylinder Power 5 HP (3.7 kW) Air cooled Dry air filter with interchangeable filter cartridges
	Engine	Kohler 3000 Series OHV Start recoil starter Supply fuel Displacement 196 cc, 1 Cylinder Power 5.5 HP (4.1 kW) Air cooled Dry air filter with interchangeable filter cartridges
	Fuel tank capacity	3,1 L eng. GX160 OHC - 3,6 L eng. EX 17 - 3,6 L eng. SH265
	Gearbox	2 forward gears + 1 reverse gear
	Clutch	with lever control on the handlebar working on the belt tensioner
	Final drive	with pinion and chain
	Standard rotary tiller	with 6 hoes and several tillers, working width 83 cm
	Hoes system diametre	32 cm
	Working width area with side disks	adjustable at 83 and 59 cm
	Working depth area without side disks	adjustable at 30, 52 and 77 cm
	Working depth	32 cm
	Max. revolutions tiller	1st gear 36 rpm – 2nd gear 132 rpm – reverse gear 40 rpm
	Carter of the tiller	bolted, pressed steel with screwed shells
	Handlebar	Height and side adjustment
	Standard features	Front transfer wheel
	Safety devices	When the user leaves the handlebars the machine stops. Mudguards and handlebars according to the law. Silencer protection.
	Weight	63 kg with eng. GX160 OHC - 65 kg with eng. EX 17 - 66 kg with eng. SH265
